Asicpy – EL Tester

Capture Type: Automation Mode, direct capture type

Applications: Solar Panel pre-lamination or post-lamination

Camera Q'ty: Quadruple camera for EL testing Quadruple camera for front VI testing Quadruple camera for rear VI testing

Camera Resolution: 2,720*1836*4*3 pixels for EL testing (5.0M) 4,000 3,000*4*3 pixels for VI testing (12M) 4,000 3,000 4 3 pixels for VI testing (12M) Trans funtion: Length-side on front

Panel Size included: 1. 12BB(round wire) PERC cells, both gap & gapless (tiling)+main, half-cut, both mono & bi-facial(with transparent + white patterned backsheet), only framed & glass to backsheet configuration 2. Cell size(to be applied): M10, M12 3. Module size: L1600-2400mm x W950-1200mm x T30-40mm 4. Gapless (tiling, switchable to normal gap type when it's required) & half-cut technology

Conveyor height: 950+30mm

Footprint: W2700mm* L2900mm

Facility Inquiry: AC 220V 50Hz (240V option) 3KW, CDA (0.6Mpa, M10)

Cycle time: <25s/pcs (excluding defect judgemet)

Transportation sample size: Length: 2000-2500mm; Width: 1000-1500mm

Applications: Solar Panel pre-lamination

Camera Qty: Quadruple camera for EL testing
Quadruple camera for VI testing

Camera Resolution: 2,720*1836* 4*3 pixels for EL testing (5M)
4,000*3,000*4*3 pixels for VI testing (12M)

Trans funtion: Length-side on front

Panel Size included: 166*83 mm/12* 6 pcs; 166*83mm/10*6 pcs; 182*91 mm/24* 6pcs;
182*91 mm/20* 6pcs;
Up to 2500* 1500mm solar panel

Conveyor height: 950130mm

Footprint: W2900mm * L2800mm

Facility Inquiry: AC 220V 50Hz (240V option), CDA (0.6Mpa, M10)

Cycle time: < 22s/pcs (excluding defect judgemet)

Optical system: Quadruple EL Camera system for EL
Quadruple EL Camera system for VI

Transportation sample size: Length: 1700~2500mm; Width: 1000 ~ 1500mm

Capture Type: Automation Mode, direct capture type

Applications:Solar string

Camera Resolution: 1,920* 1,200*2 pixels for EL testing (1.3M)

Panel Size included: 166~210 mm full cell/half cell/tri-cut cell string compatible;

Facility Inquiry:AC 220V 50Hz (240V option), CDA (0.6Mpa, M10)

Cycle time: < 6s/pcs (excluding defect judgemet)|

Optical system: Duel EL Camera system for EL

Judgement and Classifiction: Manually
